● 充电指示灯
● 水平指示器
● 安全检修支撑杆
● 围栏拆卸
● 紧急下降系统
● 紧急停止按钮
● 实心轮胎
● 标准运输叉车孔
|
型号 规格 Model Number |
FSJY3
|
|
|
平台额定载荷Lift Rated Capacity |
kg
|
240
|
|
最大工作高度Maximum working height |
mm
|
5000
|
|
最大平台高度Maximum platform height |
mm
|
3000
|
|
整机长度Overall Length |
mm
|
1180
|
|
整机宽度Overall Width |
mm
|
760
|
|
整机高度Overall Height |
mm
|
1830
|
|
工作平台尺寸Platform Size |
mm
|
1170×600
|
|
最小离地高度Ground clearance |
mm
|
60
|
|
轴距Wheel base |
mm
|
990
|
|
最小转弯半径 Minimum turn radius |
mm
|
1200
|
|
驱动电机Driver Motor |
V/kw
|
2×24/0.4
|
|
举升电机Lifting Motor |
V/kw
|
24/0.8
|
|
机器行使速度（平台降下）Running speed(platform Stowed) |
km/h
|
4
|
|
机器行使速度（平台升起）Running speed(platform Elevated) |
km/h
|
0.8
|
|
上升/下降速度Rising/falling speed |
sec
|
20/30
|
|
蓄电池Battery |
V/Ah
|
2×12/80
|
|
充电器Charger |
V/A
|
24/12
|
|
最大爬坡能力Maximum climbing ability |
%
|
10-15
|
|
工作最大允许角度Maximum working allowable angle |
/
|
2°
|
|
驱动轮 Driving Wheel |
mm
|
Φ230×80
|
|
前轮Front wheel |
in
|
6
|
|
整体重量Lifting capacity |
kg
|
490
|
